Why do quick connects affect the entire liquid-cooling system?

Support / Technical answers

Why do quick connects affect the entire liquid-cooling system?

Direct, data-backed answers to the questions that matter before and during deployment.

Quick connects concentrate leak risk. Per OCP UQD v1.0: working pressure 0-600 kPa, cycle life ≥5,000, fluid loss ≤0.07 mL per cycle (UQD08 limit), 100% helium leak testing at production. Self-sealing on disconnect, bubble-free on connect; blind-mate versions absorb misalignment.

01

Reliability metrics

Cycle life (OCP durability ≥5,000), fluid loss (≤0.07 mL per cycle), leak rate (helium ≤1×10⁻² Pa·m³/s), flow resistance (≤30 kPa at rated flow) and insertion force.

02

How it is assured

100% helium leak testing at production; cycle, pressure-surge and temperature tests validate seals; keyed anti-misplug and lock-in indicators reduce operator error.

03

What to watch

Confirm media and pressure before coupling; blind-mate needs alignment space; inspect coupling state and seals periodically.
